Bitte wählen Sie aus der folgenden Warengruppe die Artikel aus, die Sie bestellen möchten. Tragen Sie einfach die gewünschte Bestellmenge in das dazugehörige Eingabefeld ein. Um den Artikel in den Einkaufskorb zu legen, klicken Sie bitte auf den 'Bestellen' Knopf.
15cm Tief - Mitteltöner mit stabiler, verwindungsfreier Aluminiummembran und Phase Plug. Schwingspulenträger aus Aluminium, hohe Belastbarkeit und stabiler Druckgußkorb. Einsatzbereich bis 3000 Hz. Technische Daten Impedanz: 8 Ohm; Nennbelastbarkeit: 80 Watt; Musikbelastbarkeit: 200 Watt; Resonanzfrequenz (fs): 46 Hz; Gleichstromwiderstand (Re): 5,9 Ohm; Kenschalldruck (1W, 1m): 86 dB; Luftspalthöhe: 6,0 mm; Schwingspule (D; Länge): 26 mm; 16 mm; Kraftfaktor (F/I): 5.20 N/A; Schwingspuleninduktivität: 0,61 mH; Effektive Membranfläche (cm2): 75; Bewegte Masse incl. Luftlast: 7, 3 g; Äquivalentvolumen (Vas): 12,0 dm3; Aufhängungsnachgiebigkeit: 1,60mm/N; Elektrische Güte (Qes): 0,48; Mechanische Güte (Qms): 1,51; Freiluftgesamtgüte (Qts): 0,37. .
18cm Tief - Mitteltöner mit stabiler, verwindungsfreier Aluminiummembran und Phase Plug. Schwingspulenträger aus Aluminium, hohe Belastbarkeit und stabiler Druckgußkorb. Einsatzbereich bis 2500 Hz. Technische Daten Impedanz: 8 Ohm; Nennbelastbarkeit: 100 Watt; Musikbelastbarkeit: 250 Watt; Resonanzfrequenz (fs): 37 Hz; Gleichstromwiderstand (Re): 5,8 Ohm; Kenschalldruck (1W, 1m): 87 dB; Luftspalthöhe: 6,0 mm; Schwingspule (D; Länge): 39 mm; 18 mm; Kraftfaktor (F/I): 6.70 N/A; Schwingspuleninduktivität: 1,00 mH; Effektive Membranfläche (cm2): 120; Bewegte Masse incl. Luftlast: 13, 3 g; Äquivalentvolumen (Vas): 26,0 dm3; Aufhängungsnachgiebigkeit: 1,40mm/N; Elektrische Güte (Qes): 0,42; Mechanische Güte (Qms): 1,55; Freiluftgesamtgüte (Qts): 0,33. .
15 cm Tief - Mitteltöner mit stabiler, beschichteter Papiermembran. Ideales ausschwingverhalten durch hinterlüftete Zentrierspinne und Polkernbohrung. Einsatzbereich bis 4000 Hz Technische Daten Impedanz: 8 Ohm Belastbarkeit (Dauer/Kurz): 60/ 250 Watt; Resonanzfrequenz (fs): 47 Hz Gleichstromwiderstand (Re): 5,5 Ohm Kenschalldruck (1W, 1m): 87 dB Kraftfaktor (F/I): 5.40 N/A Schwingspuleninduktivität: 0,76 mH Effektive Membranfläche (cm2): 80 Bewegte Masse incl. Luftlast: 8,2 g Äquivalentvolumen (Vas): 12 dm3 Aufhängungsnachgiebigkeit: 1,4 mm/N Elektrische Güte (Qes): 0,48 Mechanische Güte (Qms): 1,70 Freiluftgesamtgüte (Qts): 0,37 Frequenzbereich: 50 - 4000 Hz Luftspalthöhe: 6,0 mm Schwingspule (D; Länge): 26 mm; 16 mm Lineare Auslenkung: +/- 5,0 mm
18 cm Tief - Mitteltöner mit stabiler, beschichteter Papiermembran. Ideales ausschwingverhalten durch hinterlüftete Zentrierspinne und Polkernbohrung. Einsatzbereich bis 3000 Hz Technische Daten Impedanz: 8 Ohm Belastbarkeit (Dauer/Kurz): 80/ 250 Watt; Resonanzfrequenz (fs): 36 Hz Gleichstromwiderstand (Re): 6,1 Ohm Kenschalldruck (1W, 1m): 88 dB Kraftfaktor (F/I): 6.40 N/A Schwingspuleninduktivität: 1,10 mH Effektive Membranfläche (cm2): 130 Bewegte Masse incl. Luftlast: 12,0 g Äquivalentvolumen (Vas): 36 dm3 Aufhängungsnachgiebigkeit: 1,6 mm/N Elektrische Güte (Qes): 0,43 Mechanische Güte (Qms): 1,70 Freiluftgesamtgüte (Qts): 0,35 Frequenzbereich: 45 - 3000 Hz Luftspalthöhe: 6,0 mm Schwingspule (D; Länge): 39 mm; 18 mm Lineare Auslenkung: +/- 6,0 mm
18 cm Tief - Mitteltöner mit stabiler, verwindungsfreier Aluminiummembran und Phase Plug. Schwingspulenträger aus Aluminium, hohe Belastbarkeit und stabiler Druckgußkorb. Bis auf die 26 mm Schwingspule baugleich mit dem W 181 AL Technische Daten Impedanz: 8 Ohm Belastbarkeit (Dauer/Kurz): 80/ 250 Watt; Resonanzfrequenz (fs): 35 Hz Gleichstromwiderstand (Re): 5,6 Ohm Kenschalldruck (1W, 1m): 88 dB Kraftfaktor (F/I): 6.40 N/A Schwingspuleninduktivität: 0,90 mH Effektive Membranfläche (cm2): 125 Bewegte Masse incl. Luftlast: 12,4 g Äquivalentvolumen (Vas): 34 dm3 Aufhängungsnachgiebigkeit: 1,7 mm/N Elektrische Güte (Qes): 0,40 Mechanische Güte (Qms): 1,73 Freiluftgesamtgüte (Qts): 0,32 Frequenzbereich: 35 - 2500 Hz Luftspalthöhe: 6,0 mm Schwingspule (D; Länge): 26 mm; 14 mm Lineare Auslenkung: +/- 4,0 mm
12 cm tiefmitteltöner mit sehr steifer Membran aus Aluminium und Phase Plug. Mit hinterlüfteter Zentrierspinne. Dadurch ideales Ausschwingverhalten. Hoch belastbar. Einsatzbereich bis 3500 Hz Technische Daten Impedanz: 8 Ohm Belastbarkeit (Dauer/Kurz): 70/220 Watt; Resonanzfrequenz (fs): 48 Hz Gleichstromwiderstand (Re): 5,5 Ohm Kenschalldruck (1W, 1m): 86 dB Kraftfaktor (F/I): 5,7 N/A Schwingspuleninduktivität: 0,80 mH Effektive Membranfläche (cm2): 50 Bewegte Masse incl. Luftlast: 5,9 g Äquivalentvolumen (Vas): 6,0 dm3 Aufhängungsnachgiebigkeit: 1,9 mm/N Elektrische Güte (Qes): 0,31 Mechanische Güte (Qms): 2,69 Freiluftgesamtgüte (Qts): 0,28 Frequenzbereich: 55 - 3500 Hz Luftspalthöhe: 6,0 mm Schwingspule (D; Länge): 26 mm; 120 mm Lineare Auslenkung: +/- 3,0 mm
SEAS LAUTSPRECHER CA12RCY H1152 Technische Daten: Bitte Artikelzeile anklicken!
Technische Daten: Bitte Artikelzeile klicken!
L15RLY/P is a 15 cm (5’’) cone driver, developed for use as a long throw high fidelity woofer or woofer/midrange unit. Stiff, yet light aluminium cone and low loss rubber surround show no sign of the familiar 500-1500 Hz cone edge resonance and distortion associated with soft cones. Large magnet system , together with very long, and light weight copper clad aluminium voice coil allow for extreme coil excursion with low distortion and good transient response. Extremely stiff and stable injection moulded metal basket, keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonances to a minimum.
ER15RLY is a 15 cm (5’’) cone driver, developed for use as a long throw high fidelity woofer or woofer/midrange unit. Edge coated reed/paper pulp cone, together with perfectly matched moving parts gives a smooth, extended frequency response. Large magnet system, together with a very long and light weight copper clad aluminium voice coil allow good coil excursion with low distortion and good transient response. Extremely stiff and stable injection moulded metal basket keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonance to a minimum.
ER18RNX is an 18 cm (6,5’’) cone driver, developed for use as a long throw high fidelity woofer or woofer/midrange unit. Edge coated reed/paper pulp cone together with perfectly matched moving parts gives a smooth, extended frequency response. Bumped back plate in the magnet system, together with the very long and light weight copper clad aluminium voice coil, allow extreme coil excursion with low distortion. Heavy copper ring below the T-shaped pole piece will reduce non linear and modulation distortion. Extremely stiff and stable injection moulded metal basket keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound reflection, air flow noise and cavity resonance to a minimum.
L18RCY/P is a 6,5” High Fidelity woofer with an injection moulded metal chassis, intended for bass reflex and transmission line designs. Stiff, yet light aluminium cone and low loss rubber surround show no sign of the familiar 500-1500 Hz cone edge resonance and distortion assosiated with soft cones. High temperature voice coil wound on an aluminium voice coil former gives a high power handling capacity. Phase plug reduces compression due to temperature variations in the voice coil, eliminates resonances that would occur in the volume between the dust cap and the pole piece and increases the power handling capacity. Large magnet system provides high efficiency and low Q.
L16RNX H1488-04 Tiefmitteltöner mit Aluminiummebran - 4 Ohm Version SEAS Spider Ring® technology. The Spider Ring® consists of a ring, the spider, voice coil, lead out wires and terminal. All parts are perfectly matched and glued together. This component can be fixed to a magnet system, and will enable us to measure the impedance and test parameters - like the resonance frequency, the damping in the spider, Re and the inductance in the voice coil before we assemble the driver! This technology will represent an example of a new generation of High End loudspeakers from Seas. Merkmale / Features / Bevat: Typ Tiefmittelton Mech.Widerstand(Ns/m) 1.88 Luftlast(g) 0.62 Magnetgewicht(Kg) 0.42 Max.Mech..Auslenkung+-(mm) 22 Korb Material Aluminium Sicke Material Gummi Membranmaterial Aluminium Einbautiefe (mm) 71 Einbaulochmaß (mm) 126 Außendurchmesser (mm) 146 VAS 16 QTS 0.33 QMS 2.31 QES 0.38 Flussdichte (T) 1.05 Gesamtgew. (Kg) 1.8 Xmax +- (mm) 12 VC (h) 18 VC (d) 39 Hag (mm) 6 Freq.(Hz) 45-2000 Cms (mm/N) 1.3 Mms/g 14.7 Sd cm2 104 VC (Le/mH) 0.32 BxL/NA (F/I) 5.4 Nominal (W) 80 Re (Ohm) 3.1 fs 37 SPL (1W/1M) 88 Music (W) 250 Imp. (Zn/ohm) 4
wie zuvor, jedoc als 8 Ohm Version
Seas Tieftöner mit gewobener Polypropylen Membran mit Seas SpiderRing® Technologie W16GP is a 5 inch High Fidelity woofer with an injection mouldedmetal chassis, intended for bass refl ex and transmission line designs.New Curv cone, a woven polypropylene with excellent internal damping together with perfectly matched moving parts gives a smooth, extended frequency response.A unique radial reinforced low loss rubber surround reduces radial resonances and prevents surround break up at large excursions.Bullet shaped phase plug reduces compression due to temperature variations in the voice coil, avoids resonance problems which would occur in the volume between thedust cap and the pole piece and increases the long term power handlingcapacity.Extremely stiff and stable injection moulded metal basket, keeps the critical compo-nents in perfect alignment. Large windows in the basket both above and below the spider reduce sound refl ection, air fl ow noise and cavity resonance to a minimum.This driver use Seas SpiderRing® technology
L16RN-SL-08 Seas High Fidelity Woofer mit Aluminium Membran. Bevorzugter Anwendungsbereich: Bassreflex oder Transmissionline SEAS Spider Ring® technology. The Spider Ring® consists of a ring, the spider, voice coil, lead out wires and terminal. All parts are perfectly matched and glued together. This component can be fixed to a magnet system, and will enable us to measure the impedance and test parameters - like the resonance frequency, the damping in the spider, Re and the inductance in the voice coil before we assemble the driver! This technology will represent an example of a new generation of High End loudspeakers from Seas. Technische Daten: Typ Tiefmittelton Mech.Widerstand(Ns/m) 5.41 Luftlast(g) 0.62 Magnetgewicht(Kg) 0.42 Max.Mech..Auslenkung+-(mm) 22 Korb Material Aluminium Sicke Material Gummi Membranmaterial Aluminium Einbautiefe (mm) 74 Einbaulochmaß (mm) 126 Außendurchmesser (mm) 146 VAS 19 QTS 0.46 QMS 2.47 QES 0.56 Flussdichte (T) 0.88 Gesamtgew. (Kg) 1.4 Xmax +- (mm) 12 VC (h) 18 VC (d) 39 Hag (mm) 6 Freq.(Hz) 45-2000 Cms (mm/N) 1.3 Mms/g 14.8 Sd cm2 104 VC (Le/mH) 0.68 BxL/NA (F/I) 6.2 Nominal (W) 80 Re (Ohm) 6.1 fs 36 SPL (1W/1M) 84 Music (W) 250 Imp. (Zn/ohm) 8
The W18GP is a 6.5 High Fidelity woofer with an injection moulded metal chassis, intended for bass refl ex and transmission line designs. New Curv cone, a woven polypropylene with excellent internal damping together with perfectly matched moving parts gives a smooth, extended frequency response. Bumped back plate in the magnet system, together with the very long and light weight copper clad aluminium voice coil, allow extreme coil excursion with low distortion. Heavy copper ring below the T-shaped pole piece will reduce non linear and modulation distortion. Bullet shaped phase plug reduces compression due to temperature variations in the voice coil, avoids resonance problems which would occur in the volume between the dust cap and the pole piece and increases the long term power handling capacity. Extremely stiff and stable injection moulded metal basket, keeps the critical components in perfect alignment. Large windows in the basket both above and below the spider reduce sound refl ection, air fl ow noise and cavity resonance to a minimum.
P18RNX/P Tiefmitteltöner mit Polypropylen Membran The P18RNX/P is an 18 cm (6,5¿¿) cone driver, developed for use as a long throw high fi delity woofer or woofer/midrange unit. A polypropylene based cone ensures smooth frequency respons and low distortion, and the adaptive rubber surround provides an ideal match to the cone over the total frequency range.
Merkmale Korbmaß (Zoll) 8 Imp. (Zn/ohm) 8 Freq.(Hz) 29-4000 Music (W) 100 Nominal (W) 250 SPL (1W/1M) 90,50 VC (d) 39 VC (h) 14 Hag (mm) 6,00 Xmax +- (mm) 8,00 Max.Mech..Auslenkung+-(mm) 20,00 Flussdichte (T) 1,00 Magnetgewicht(Kg) ,64 Gesamtgew. (Kg) 2,20 Re (Ohm) 6,00 LE (VC/mH) ,7000 BL (NA) (F/I) 8,00 fs 29 Mms(g) 19,8 Luftlast(g) 1,90 Cms (mm/N) 1,70 Mech.Widerstand(Ns/m) 2,10 Sd (cm2) 220 VAS 103,00 QMS 1,77 QES ,34 QTS ,29
